eCity

Motor M131VD

Parameter

Physical Features

Construction : Gear Drive

Weight : 2.5 Kg

Noise Grade : ≤55 dB

Performance & Technical

Rated Voltage : 36V / 48V DC

Rated Power : 250 W

Max Torque : 40 N.m

Key points

reliable and affordable

Options

Available in 250W Only

Learn More Inquiry Now
Construction Gear Drive
Weight (Kg) 2.5
Color Black
Noise Grade (dB) ≤55
Operation Temperature (°C) -20~55
Brake Type Disc Brake / V Brake
Cable Routing Shaft side, Right
Spoke specification 36H*13G
Free wheel /
Rated Voltage (DC) 36V / 48V
Rated Power (W) 250
Max Torque (N.m) 40
Max efficiency ≥80%
Certifications UL / CE / RoHS / REACH
Waterproof IPX6
Cable Length (mm) 250
blank
A: 44.5mm
B: 139.5mm
C: 126.5mm
D: M12x1.25mm
E: 10mm
F: 10mm
O.L.D: 100

Comparison Motor

O.L.D
Construction
Rated Voltage (DC)
Rated Power (W)
Max Torque (N.m)
Max efficiency
Weight (Kg)
Color
Noise Grade (dB)
Operation Temperature (°C)
Brake Type
Cable Routing
Cable length
Spoke specification
Free wheel
Certifications
Waterproof
blank

M131VD

eCity

100
Gear Drive
36V / 48V
250
40
≥80%
2.5
Black
≤55
-20~55
Disc Brake / V Brake
Shaft side, Right
36H*13G
/
UL / CE / RoHS / REACH
IPX6
blank

M108VD

eCity

100
Gear Drive
36V
250
30
≥80%
2
Grey / Sliver
≤50
-20~55
Disc Brake / V Brake
Through shaft,Left
36H*13G
/
CE / RoSH / REACH
IPX5
blank

Motor eBike System

Discover
blank
Motor M108VD
Learn More blank
Systems eCity
Rated Power 250 W
Max Torque 30 N.m
Weight 2 Kg

Inquiry Now

For more details about our engine, please leave your contact information. We will promptly call you back to address any inquiries you may have.
